BALL VALVES

72

● Widely used in a variety of fluid systems;

● The maximum operating pressure can reach 3000 psig (207 bar) at operating temperature 10℃ ~ 90℃.

● Low temperature compensation type operating temperature -10 ℃ ~ 90 ℃;

● Available in straights or angle;

● Can be used for panel mounting;

●Available in 1/16in. ~ 3/4in.; 2mm ~ 14mm, Tube Fitting and threaded connections.

73

● Widely used in a variety of fluid systems;

● The maximum operating pressure can reach 2500psig (172bar)at Operating temperature is 10℃ ~ 90℃;

● Low temperature compensation type operating temperature -10℃ ~ 90℃;

● Can be used for panel mounting;

● Available in sizes from 1/16in. to 1/2in.; 2mm to 14mm Tube Fitting and threaded connections.

R72

● Widely used in a variety of fluid systems;

● The maximum operating pressure up to 6000psig (413bar), at operating temperature is -17℃ ~ 204℃ (with fluorine rubber);

● Can be used for panel mounting;

● Available in 1/16in. to 1/2in.; 2mm ~ 12mm Tube Fitting and threaded connections.

On-off，switching and crossover/diversion flow paths

74

● Widely used in a variety of fluid systems;

● The maximum operating pressure up to 2000psig (138bar) at maximum operating temperatures of 10℃ ~ 90℃;

● Can be used for panel mounting;

● Available in sizes from 1/16in. to 1/4in.; 2mm to 6mm, Tube Fitting and threaded connections.

75

● Widely used in a variety of fluid systems;

● The maximum operating pressure up to 2000psig (138bar) at maximum operating temperatures of 10℃ ~ 90℃;

● Can be used for panel mounting;

● Available in sizes from 1/16in. to 1/4in.; 2mm to 6mm, Tube Fitting and threaded connections.

76

● Widely used in a variety of fluid systems;

● The maximum operating pressure up to 500psig (34.5bar) at Operating temperature is 10℃ ~ 90℃;

● Can be used for panel mounting;

● Available in 1/16in. to 1/8in.; 2mm ~ 3mm Tube Fitting and threaded connections.

77

● Widely used in a variety of fluid systems;

● The maximum operating pressure up to 500psig (34.5bar) at Operating temperature is 10℃ ~ 90℃;

● Can be used for panel mounting;

● Available in 1/16in. to 1/8in.; 2mm ~ 3mm Tube Fitting and threaded connections.
